| 產品名稱 | 聚酯膠帶 | |||
| 產品編號 | No.31B | No.31C | ||
| 粘合劑 | 丙烯酸 | |||
| 襯背厚度/總厚度
[mm] |
0.025/0.053 | 0.050/0.080 | 0.025/0.053 | 0.050/0.080 |
| 標準長度 [m]
[內徑 (mm)] |
50[75Φ] | |||
| 顏色 | 透明 | 白色、黃色、紅色、綠色、藍色、黑色 | ||
| 剝離強度
[N/19 mm] |
5.5 | 7.5 | 5.5 | 7.5 |
| 抗拉強度
[N/19 mm] |
100 | 196 | 100 | 196 |
| 延展率 [%] | 110 | 130 | 110 | 130 |
| 擊穿電壓 [kV] | 5.5 | 8.0 | 7.0 | 11.0 |
| 電解腐蝕系數 | 1.00 | |||
| 產品名稱 | 聚酯膠帶 | |||
| 產品編號 | No.31RH | |||
| 粘合劑 | 丙烯酸 | |||
| 襯背厚度/總厚度
[mm] |
0.025/0.053 | 0.050/0.080 | 0.025/0.053 | 0.050/0.080 |
| 標準長度 [m]
[內徑 (mm)] |
50[75Φ] | |||
| 顏色 | 透明 | 白，黃，紅
綠色、黑色 |
紅色、藍色 | |
| 剝離強度
[N/19 mm] |
6.5 | 8.5 | 6.5 | 8.5 |
| 抗拉強度
[N/19 mm] |
100 | 196 | 100 | 196 |
| 延展率 [%] | 110 | 130 | 110 | 130 |
| 擊穿電壓 [kV] | 5.5 | 8.0 | 7.0 | 11.0 |
| 電解腐蝕系數 | 1.00 | |||
| 產品名稱 | 聚酯膠帶 | ||
| 產品編號 | No.31D | No.31E | |
| 粘合劑 | 橡膠 | ||
| 襯背厚度/總厚度
[mm] |
0.025/0.053 | 0.050/0.080 | 0.025/0.053 |
| 標準長度 [m]
[內徑 (mm)] |
50[75Φ] | ||
| 顏色 | 透明 | 白，黃，紅
?藍色、黑色 |
|
| 剝離強度
[N/19 mm] |
5.5 | 7.0 | 5.5 |
| 抗拉強度
[N/19 mm] |
100 | 196 | 100 |
| 延展率 [%] | 110 | 130 | 110 |
| 擊穿電壓 [kV] | 5.5 | 8.0 | 7.0 |
| 電解腐蝕系數 | 1.00 | ||
| 產品名稱 | 熱固性聚酯 | |||
| 產品編號 | No.315 | |||
| 粘合劑 | 熱固性橡膠 | |||
| 襯背厚度/總厚度
[mm] |
0.025/0.060 | 0.050/0.085 | 0.025/0.060 | 0.050/0.085 |
| 標準長度 [m]
[內徑 (mm)] |
50[75Φ] | |||
| 顏色 | 透明 | 黃色 | ||
| 剝離強度
[N/19 mm] |
12.0 | 14.5 | 12.0 | 14.5 |
| 抗拉強度
[N/19 mm] |
100 | 196 | 100 | 196 |
| 延展率 [%] | 110 | 130 | 110 | 130 |
| 擊穿電壓 [kV] | 5.5 | 8.0 | 7.0 | 11.0 |
| 電解腐蝕系數 | 1.00 | |||
